A Do-It-Yourself Fireplace Reflector
Things Needed
-
Tape measure
-
Stainless steel sheet, heavy duty, 14-gauge type 304
-
Standard fireplace bricks (4 to 6)
A simple fireplace reflector is a stainless steel sheet held vertical to your fireplace floor by metal fireback supports. It is placed between your fire and the back wall of your fireplace. An important consideration is fitting the fireplace reflector to the size of the back wall of the fireplace so the maximum heat will be reflected out into the room. Another benefit of a fireplace reflector is it protects the walls of your fireplace from the heat generated by your fires over the years, and may extend the life of the fireplace. There are several creative solutions if you don't want to buy a commercial fireplace reflector.
Step 1
Clean your fireplace thoroughly and paint it, if necessary. This will make it easier to install the fireplace reflector properly.
Step 2
Measure the back of your fireplace. Most commercially-made fireplace reflectors come in the following common sizes: 15 inches by 15 inches, 16 inches by 18 inches and 20 inches by 20 inches.
Step 3
Buy a sheet of heavy duty, 14-gauge 304 stainless steel in the appropriate size to fit your fireplace. It should be at least as wide as the area occupied by the fire or gas flame but, if your fireplace is large, extend the width by a few inches to maximize heat reflection. A standard large screen is 20 inches in width.
Step 4
Construct a fireback support by placing four to six standard fireplace bricks in pairs along the back wall floor of your fireplace. Stand them on their sides, parallel to the back wall. Place the steel sheet between the pairs of bricks so it stands vertical to the floor of the fireplace, held in place by the bricks.
Step 5
Adjust the reflector so it points directly toward the room, not at an angle. Also adjust the bend of your rim so it doesn't interfere with the draw of smoke through the flue.
Tip
For a less-involved project, lining the back of your fireplace with aluminum foil can work if your fireplace is deep enough and the fire does not sit close enough to the foil to damage it. Another creative solution is to paint the back of the fireplace with Krylon heat-resistant paint in a metallic silver or white color that will reflect heat. A third creative solution is to use a simple flat steel cookie sheet, if it fits, and position it against the back wall of your fireplace using the bricks.
Warning
Before working on your fireplace project, let the fireplace cool down until it is cool to the touch. Take care when you clean out the ashes from your fireplace so you don't scatter dust. If you have a gas fireplace, be careful to avoid damaging the apparatus and test it to make sure it still works before assuming all is working perfectly. Also check the positioning and stability of your reflector from time to time so it doesn't accidentally fall on the fire or move out of alignment.
